UCC5614PWPTRG4

Texas Instruments
RoHS
RoHS RoHS compliant
Package 24-TSSOP (0.173, 4.40mm Width) Exposed Pad
Category Integrated Circuits (ICs) / Interface - Signal Terminators
Description Lead Free Obsolete BICMOS GULL WING SCSI Terminator 0C~70C 110Ohm 218mA 1.2mm
PDF
/
Inventory: 3661
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width 4.4mm
Length 7.8mm
Height Seated (Max) 1.2mm

Technical

Pull-up Resistance-Nom 110Ohm
Number of Signal Lines 9
Differential Output NO
Nominal Supply Current 218mA
Power Supplies 3/5V
Operating Supply Voltage 5.25V
Pin Count 24
Base Part Number UCC5614
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.7V~5.25V
Technology BICMOS
Subcategory Bus Terminators
Resistance 110Ohm
Type SCSI
Number of Terminations 9
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C

Physical

Number of Pins 24
Package / Case 24-TSSOP (0.173, 4.40mm Width) Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
