DS2125 image
Favorite
RoHS
/
Package 48-LQFP
Category Integrated Circuits (ICs) / Interface - Signal Terminators
Description Obsolete BICMOS GULL WING Non-RoHS Compliant SCSI, LVD, SE Terminator 0C~70C 110Ohm 1.6mm 3.3V
PDF
/
Inventory: 4009
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mounting Type Surface Mount
Package / Case 48-LQFP
Surface Mount YES

Technical

Operating Temperature 0°C~70°C
Packaging Tube
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 15
Type SCSI, LVD, SE
Terminal Finish TIN LEAD
Technology BICMOS
Voltage - Supply 2.7V~5.5V
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 48
JESD-30 Code S-PQFP-G48
Qualification Status COMMERCIAL
Differential Output YES
Number of Signal Lines 15
Pull-up Resistance-Nom 110Ohm

Dimensions

Height Seated (Max) 1.6mm
Length 7mm
Width 7mm

Compliance

RoHS Status Non-RoHS Compliant
