DS21T05Z+
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Signal Terminators
Description
Lead Free Obsolete GULL WING ROHS3Compliant SCSI, LVD, SE Terminator 0C~70C 110Ohm 1.75mm 5V
PDF
/
Buying Options
Total Price: USD $4.03
Unit Price: USD $4.028
≥1 USD $4.028
≥10 USD $3.30505
≥100 USD $3.2015
≥500 USD $3.09795
≥1000 USD $2.99535
Inventory: 6599
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 1.75mm
Technical
Pull-up Resistance-Nom 110Ohm
Number of Signal Lines 9
Differential Output NO
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G16
Pin Count 16
Base Part Number DS21T05
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4V~5.5V
Terminal Finish Matte Tin (Sn)
Type SCSI, LVD, SE
Number of Terminations 9
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2013
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Surface Mount YES
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
