DS2120E
RoHS
/
Package 28-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Interface - Signal Terminators
Description
Contains Lead Obsolete GULL WING Non-RoHS Compliant SCSI, LVD, SE Terminator 0C~70C 105Ohm 1.1mm 3/5V
PDF
/
Buying Options
Total Price: USD $1.67
Unit Price: USD $1.665539
≥1 USD $1.665539
≥10 USD $1.571271
≥100 USD $1.482324
≥500 USD $1.398416
≥1000 USD $1.319267
Inventory: 1240
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 28-TSSOP (0.173, 4.40mm Width)
Surface Mount YES
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Published 2006
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 9
Type SCSI, LVD, SE
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Bus Terminators
Voltage - Supply 2.7V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Terminal Pitch 0.65mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 20
Base Part Number DS2120
Pin Count 28
JESD-30 Code R-PDSO-G28
Qualification Status Not Qualified
Power Supplies 3/5V
Differential Output YES
Number of Signal Lines 9
Pull-up Resistance-Nom 105Ohm
Dimensions
Height Seated (Max) 1.1mm
Width 4.4mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
