DS2120B
RoHS
/
Package 36-BSOP (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - Signal Terminators
Description
Contains Lead Obsolete GULL WING Non-RoHS Compliant SCSI, LVD, SE Terminator 0C~70C 105Ohm 2.64mm 3/5V
PDF
/
Buying Options
Total Price: USD $2.76
Unit Price: USD $2.7626
≥1 USD $2.7626
≥10 USD $2.2667
≥100 USD $2.1964
≥500 USD $2.12515
≥1000 USD $2.05485
Inventory: 3635
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 36-BSOP (0.295, 7.50mm Width)
Surface Mount YES
Number of Pins 36
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Published 2006
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 9
Type SCSI, LVD, SE
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Bus Terminators
Voltage - Supply 2.7V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Number of Functions 1
Terminal Pitch 0.8mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number DS2120
Pin Count 36
Qualification Status Not Qualified
Power Supplies 3/5V
Differential Output YES
Number of Signal Lines 9
Pull-up Resistance-Nom 105Ohm
Dimensions
Height Seated (Max) 2.64mm
Length 15.375mm
Width 7.5mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
