SN65LVDS17DRFTG4
RoHS
RoHS compliant
RoHS compliantPackage 8-WFDFN Exposed Pad
Category Integrated Circuits (ICs) / Interface - Signal Buffers, Repeaters, Splitters
Description
Nickel/Palladium/Gold (Ni/Pd/Au) 65LVDS17 Tape & Reel (TR) BICMOS signal splitter 2.5/3.3V 0.5mm -40C~85C 48mA
PDF
/
Buying Options
Total Price: USD $2.15
Unit Price: USD $2.14605
≥1 USD $2.14605
≥10 USD $1.7613
≥100 USD $1.7062
≥500 USD $1.6511
≥1000 USD $1.596
Inventory: 1444
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-WFDFN Exposed Pad
Number of Pins 8
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type Buffer, ReDriver
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Other Interface ICs
Technology BICMOS
Voltage - Supply 2.375V~3.6V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 2.5V
Terminal Pitch 0.5mm
Base Part Number 65LVDS17
Output LVDS
Pin Count 8
Power Supplies 2.5/3.3V
Operating Supply Current 48mA
Number of Bits 1
Logic Function Buffer
Input PECL
Data Rate (Max) 4Gbps
Number of Receivers 1
Delay Time 460ps
Delay-Max 0.63 ns
Dimensions
Height 800μm
Length 2mm
Width 2mm
Thickness 750μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
