NB7NPQ1002MMTTWG
RoHS
RoHS compliant
RoHS compliantPackage 30-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / Interface - Signal Buffers, Repeaters, Splitters
Description
QUAD NO LEAD ROHS3Compliant Input Equalization signal buffer 10Gbps 115mA -40C~85C TA 0.4mm
PDF
/
Buying Options
Total Price: USD $2.12
Unit Price: USD $2.1208
≥1 USD $2.1208
≥10 USD $1.90256
≥100 USD $1.794848
≥500 USD $1.435808
≥1000 USD $1.256288
≥3000 USD $1.220402
Inventory: 3083
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Package / Case 30-WFQFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 30
Type Buffer, ReDriver
Terminal Finish Tin (Sn)
Applications USB
Voltage - Supply 3V~3.6V
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 0.4mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XQCC-N30
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 3V
Number of Channels 2
Current - Supply 115mA
Input CML
Data Rate (Max) 10Gbps
Signal Conditioning Input Equalization
Dimensions
Height Seated (Max) 0.8mm
Length 4.5mm
Compliance
RoHS Status ROHS3 Compliant
