MAX9180EXT+T
RoHS
RoHS compliant
RoHS compliantPackage 6-TSSOP, SC-88, SOT-363
Category Integrated Circuits (ICs) / Interface - Signal Buffers, Repeaters, Splitters
Description
Nickel/Palladium/Gold (Ni/Pd/Au) MAX9180 Tape & Reel (TR) CMOS signal buffer 50mV 1mm -40C~85C 15mA
PDF
/
Buying Options
Total Price: USD $7.89
Unit Price: USD $7.8936
≥1 USD $7.8936
≥10 USD $7.128
≥100 USD $6.796064
≥500 USD $5.901104
≥1000 USD $5.635872
≥3000 USD $5.138602
Inventory: 16641
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Width 1.35mm
Length 2.2mm
Height 1mm
Technical
Delay Time 2.0ns
Number of Receivers 1
Data Rate (Max) 400Mbps
Driver Number of Bits 1
Input Characteristics DIFFERENTIAL
Max Input Voltage 50mV
Min Input Voltage -50mV
Max Output Voltage 450mV
Turn On Delay Time 2.8 ns
Propagation Delay 2.8 ns
Max Supply Current 15mA
Operating Supply Current 10mA
Operating Supply Voltage 3.3V
Pin Count 6
Output LVDS
Base Part Number MAX9180
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~3.6V
Technology CMOS
Max Power Dissipation 245mW
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Buffer, ReDriver
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Published 2004
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Weight 28.009329mg
Number of Pins 6
Package / Case 6-TSSOP, SC-88, SOT-363
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
