LTC4314CGN#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 20-SSOP (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Signal Buffers, Repeaters, Splitters
Description
Not Qualified Matte Tin (Sn) LTC4314 Tape & Reel (TR) signal splitter 3.3V 0.635mm 0C~70C 7.3mA
PDF
/
Buying Options
Total Price: USD $2.4
Unit Price: USD $2.401294
≥1 USD $2.401294
≥10 USD $2.092763
≥30 USD $1.907644
≥100 USD $1.722525
≥500 USD $1.635873
≥1000 USD $1.597799
Inventory: 1147
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Surface Mount
Package / Case 20-SSOP (0.154, 3.90mm Width)
Surface Mount YES
Technical
Operating Temperature 0°C~70°C
Packaging Tape & Reel (TR)
Published 2010
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
ECCN Code EAR99
Type Buffer, Multiplexer
Terminal Finish Matte Tin (Sn)
Applications I2C - Hotswap
HTS Code 8542.39.00.01
Technology CMOS
Voltage - Supply 2.9V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 0.635mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number LTC4314
Output 2-Wire Bus
Pin Count 20
JESD-30 Code R-PDSO-G20
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 2.9V
Number of Channels 1 x 1:4
Adjustable Threshold NO
Current - Supply 7.3mA
Input 2-Wire Bus
Data Rate (Max) 400kHz
Capacitance - Input 20pF
Dimensions
Height Seated (Max) 1.75mm
Length 8.64mm
Width 3.899mm
Compliance
RoHS Status ROHS3 Compliant
