LTC1694-1CS5#TRMPBF image
Favorite
LTC1694-1CS5#TRMPBF image
Favorite
RoHS
RoHS RoHS compliant
Package SOT-23-5 Thin, TSOT-23-5
Category Integrated Circuits (ICs) / Interface - Signal Buffers, Repeaters, Splitters
Description Matte Tin (Sn) LTC1694 Tape & Reel (TR) CMOS signal repeater 5V 2.9mm 0C~70C 60muA
PDF
/
Buying Options
Total Price: USD $4.5
Unit Price: USD $4.4968
≥1 USD $4.4968
≥10 USD $4.04008
≥100 USD $3.819552
≥500 USD $3.310296
≥1000 USD $3.140579
Inventory: 1394
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Length 2.9mm

Technical

Data Rate (Max) 100kHz
Input 2-Wire Bus
Current - Supply 60μA
Interface 2-Wire, I2C, SMBus
Number of Channels 1
Supply Voltage-Min (Vsup) 2.7V
Supply Voltage-Max (Vsup) 6V
Pin Count 5
Output 2-Wire Bus
Base Part Number LTC1694
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 250
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.7V~6V
Technology CMOS
Applications I2C
Terminal Finish Matte Tin (Sn)
Type Buffer, Accelerator
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C

Physical

Number of Pins 5
Package / Case SOT-23-5 Thin, TSOT-23-5
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Lifecycle Status PRODUCTION (Last Updated: 4 weeks ago)
Factory Lead Time 8 Weeks
