PI2EQX3201BZFE
RoHS
RoHS compliant
RoHS compliantPackage 36-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / Interface - Signal Buffers, Repeaters, Splitters
Description
Matte Tin (Sn) PI2EQX3201 Tray e3 signal repeater 1.8V 0.5mm 0C~70C 3.2Gbps
PDF
/
Buying Options
Total Price: USD $1.07
Unit Price: USD $1.07445
≥1 USD $1.07445
≥10 USD $0.8816
≥100 USD $0.85405
≥500 USD $0.8265
≥1000 USD $0.79895
Inventory: 8160
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 5mm
Length 6mm
Height Seated (Max) 0.8mm
Technical
Signal Conditioning Input Equalization, Output De-Emphasis
Delay Time 2.0ns
Data Rate (Max) 3.2Gbps
Input CML
Number of Channels 2
Power Supplies 1.8V
Base Part Number PI2EQX3201
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.5mm
Supply Voltage 1.8V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Voltage - Supply 1.5V 1.8V
Subcategory Other Interface ICs
Terminal Finish Matte Tin (Sn)
Type Buffer, ReDriver
ECCN Code EAR99
Number of Terminations 36
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series ReDriver?
Packaging Tray
Operating Temperature 0°C~70°C
Physical
Number of Pins 36
Surface Mount YES
Package / Case 36-WFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 4 Weeks
