LM2506GRX/NOPB
RoHS
RoHS compliant
RoHS compliantPackage 49-VFBGA
Category Integrated Circuits (ICs) / Interface - Serializers, Deserializers
Description
BALL Serializer/Deserializer Surface Mount ROHS3Compliant Serializer/Deserializer -30C~85C TA 320Mbps 1.74V~3V 1.81.8/3V
PDF
/
Inventory: 5963
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 4mm
Length 4mm
Height Seated (Max) 1.1mm
Technical
Interface Standard GENERAL PURPOSE
Interface IC Type LINE TRANSCEIVER
Input Characteristics STANDARD
Differential Output NO
Number of Inputs 22/3
Data Rate 320Mbps
Input Type LVCMOS
Number of Bits 18
Power Supplies 1.81.8/3V
Output Type MPL
Number of Outputs 3/22
Function Serializer/Deserializer
Base Part Number LM2506
Terminal Pitch 0.5mm
Supply Voltage 1.8V
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Voltage - Supply 1.74V~3V
Subcategory Line Driver or Receivers
HTS Code 8542.39.00.01
ECCN Code EAR99
Number of Terminations 49
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Packaging Tape & Reel (TR)
Operating Temperature -30°C~85°C TA
Physical
Number of Pins 49
Package / Case 49-VFBGA
Mounting Type Surface Mount
Mount Surface Mount
