DS90UB902QSQ/NOPB
RoHS
RoHS compliant
RoHS compliantPackage 40-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / Interface - Serializers, Deserializers
Description
DS90UB902 Tape & Reel (TR) ACTIVE (Last Updated: 4days ago) FPD-Link III LVDS interface deserializer 800mum 96mA 1.71V~1.89V 3V~3.6V 688Mbps
PDF
/
Buying Options
Total Price: USD $12.08
Unit Price: USD $12.0821
≥1 USD $12.0821
≥10 USD $9.91325
≥100 USD $9.60355
≥500 USD $9.29385
≥1000 USD $8.98415
Inventory: 1451
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 40-WFQFN Exposed Pad
Number of Pins 40
Technical
Operating Temperature -40°C~105°C TA
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q100
JESD-609 Code e3
Feature I2C
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 40
ECCN Code EAR99
Type Integrated Circuit (IC)
Terminal Finish Matte Tin (Sn)
Subcategory Line Driver or Receivers
Voltage - Supply 1.71V~1.89V 3V~3.6V
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Terminal Pitch 0.5mm
Base Part Number DS90UB902
Function Deserializer
Number of Outputs 14
Output Type LVCMOS
Operating Supply Voltage 1.8V
Supply Current-Max 96mA
Input Type FPD-Link III, LVDS
Data Rate 688Mbps
Output Characteristics 3-STATE
Differential Output YES
Output Polarity TRUE
Max Frequency 43MHz
Number of Drivers 16
Supply Voltage1-Nom 1.8V
Number of Receivers 1
Dimensions
Height 800μm
Length 6mm
Width 6mm
Thickness 750μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
