MAX9242EUM/V+
RoHS
RoHS compliant
RoHS compliantPackage 48-TFSOP (0.240, 6.10mm Width)
Category Integrated Circuits (ICs) / Interface - Serializers, Deserializers
Description
LINE RECEIVER MAX9242 Tube LVDS interface deserializer 12.5mm 3V~3.6V 306Mbps -40C~85C TA
PDF
/
Inventory: 5671
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 6.1mm
Length 12.5mm
Height Seated (Max) 1.1mm
Technical
Interface Standard EIA-644; TIA-644
Receiver Number of Bits 3
Interface IC Type LINE RECEIVER
Input Characteristics STANDARD
Differential Output YES
Number of Inputs 3
Data Rate 306Mbps
Input Type LVDS
Operating Supply Voltage 3.6V
Output Type LVCMOS, LVTTL
Qualification Status Not Qualified
Number of Outputs 21
Function Deserializer
Base Part Number MAX9242
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~3.6V
Subcategory Line Driver or Receivers
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 48
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series Automotive, AEC-Q100
Published 2010
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Weight 420.990418mg
Number of Pins 48
Surface Mount YES
Package / Case 48-TFSOP (0.240, 6.10mm Width)
Mounting Type Surface Mount
