MPR121QR2

NXP USA Inc.
RoHS
RoHS RoHS compliant
Package 20-UFQFN
Category Integrated Circuits (ICs) / Interface - Sensor, Capacitive Touch
Description S-XQCC-N20 Buttons Slider Wheel 2003 Tape & Reel (TR) capacitive touch sensor 3mm 393muA 2V~3.6V -40C~85C
PDF
/
Buying Options
Total Price: USD $2.06
Unit Price: USD $2.06428
≥1 USD $2.06428
≥10 USD $1.94743
≥100 USD $1.8372
≥500 USD $1.73321
≥1000 USD $1.6351
Inventory: 5875
Minimum: 1
-
+

Technical Details

Physical

Mounting Type Surface Mount
Package / Case 20-UFQFN
Surface Mount YES

Technical

Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2003
Part Status Discontinued
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 20
Type Buttons, Slider, Wheel
HTS Code 8542.39.00.01
Voltage - Supply 2V~3.6V
Terminal Position QUAD
Terminal Form NO LEAD
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 0.4mm
JESD-30 Code S-XQCC-N20
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 2V
Interface I2C
Current - Supply 393μA
Number of Inputs Up to 12
Proximity Detection Yes
LED Driver Channels Up to 8

Dimensions

Height Seated (Max) 0.6mm
Length 3mm
Width 3mm

Compliance

RoHS Status ROHS3 Compliant
