CAP1208-1-SL-TR
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Sensor, Capacitive Touch
Description
CAP1208 Buttons 2014 Tape & Reel (TR) capacitive touch sensor 3.9mm 750muA 8b 3V~5.5V
PDF
/
Buying Options
Total Price: USD $0.94
Unit Price: USD $0.9416
≥1 USD $0.9416
≥10 USD $0.88
≥100 USD $0.7832
Inventory: 9477
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Height Seated (Max) 1.75mm
Technical
Proximity Detection No
Resolution 8 b
Number of Inputs 8
Operating Supply Current 750μA
Interface I2C, SMBus
Number of Channels 8
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 5.5V
Base Part Number CAP1208
Terminal Pitch 1.27mm
Supply Voltage 3.3V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~5.5V
Additional Feature IT ALSO OPERATES AT 5 V
Type Buttons
Number of Terminations 14
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Published 2014
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 16
Surface Mount YES
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
