CY8C20142-SX1I
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Sensor, Capacitive Touch
Description
e4 Buttons 2007 Tube capacitive touch sensor 3.9mm 1.5mA 2.4V~5.25V -40C~85C
PDF
/
Buying Options
Total Price: USD $1.01
Unit Price: USD $1.012
≥1 USD $1.012
Inventory: 1103
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Number of Pins 8
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2007
Series CapSense? Express?
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 8
ECCN Code EAR99
Type Buttons
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature SRAM IS ORGANISED AS 512MB
Technology CMOS
Voltage - Supply 2.4V~5.25V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 8
Supply Voltage-Max (Vsup) 5.25V
Interface I2C
Operating Supply Current 1.5mA
Nominal Supply Current 1.5mA
RAM Size 512B
Memory Type ROMless
Peripherals I2C, PWM
Watchdog Timer Yes
Data Rate 400 kbps
Number of Inputs Up to 4
Organization 2KX1
Memory Width 1
Number of GPIO 4
Proximity Detection No
LED Driver Channels Up to 4
Dimensions
Height Seated (Max) 1.727mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
