PGA309AIPWR
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Interface - Sensor and Detector Interfaces
Description
PGA309 5V 1.2mA 5V 1.2mm
PDF
/
Buying Options
Total Price: USD $6.05
Unit Price: USD $6.0544
≥1 USD $6.0544
≥10 USD $5.4692
≥100 USD $5.214528
≥500 USD $4.527864
≥1000 USD $4.324355
≥3000 USD $3.942805
Inventory: 1364
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Number of Pins 16
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Type Signal Conditioner
Subcategory Other Analog ICs
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Base Part Number PGA309
Pin Count 16
Output Type Voltage
Power Supplies 5V
Number of Channels 2
Interface UART
Max Supply Voltage 5V
Min Supply Voltage 2.7V
Operating Supply Current 1.2mA
Input Type Logic
Number of Inputs 2
Output Current per Channel 50mA
Bandwidth 400 kHz
Dimensions
Height 1.2mm
Length 5mm
Width 4.4mm
Thickness 1mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
