ADM1022ARQ-REEL7
RoHS
/
Package 16-SSOP (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Sensor and Detector Interfaces
Description
ADM1022A IC Temperature Sensor 0C~85C 4.9022mm 2.6mA 3.3V
PDF
/
Buying Options
Total Price: USD $4.76
Unit Price: USD $4.7608
≥1 USD $4.7608
Inventory: 1478
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 3.9116mm
Length 4.9022mm
Height Seated (Max) 1.7526mm
Technical
Current - Supply 2.6mA
Input Type Logic
Adjustable Threshold NO
Number of Channels 2
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 5.5V
Output Type Analog
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G16
Pin Count 16
Base Part Number ADM1022A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Terminal Pitch 0.635mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
HTS Code 8542.39.00.01
Additional Feature STAND BY MODE
Terminal Finish TIN LEAD
Type Temperature Sensor
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Published 2000
Packaging Tape & Reel (TR)
Operating Temperature 0°C~85°C
Physical
Surface Mount YES
Package / Case 16-SSOP (0.154, 3.90mm Width)
Mounting Type Surface Mount
