RE46C166SW16TF
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - Sensor and Detector Interfaces
Description
RE46C166 12V 6muA 9V 4.953mm
PDF
/
Inventory: 6753
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.112mm
Length 19.685mm
Height 4.953mm
Technical
Input Type Photoelectric
Quiescent Current 5.5μA
Operating Supply Current 6μA
Supply Voltage-Min (Vsup) 6V
Power Supplies 9V
Operating Supply Voltage 12V
Output Type Voltage
Qualification Status Not Qualified
Pin Count 16
Base Part Number RE46C166
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 1.27mm
Supply Voltage 9V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Other Analog ICs
HTS Code 8542.39.00.01
Terminal Finish Matte Tin (Sn)
Type Smoke Detector
Termination SMD/SMT
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -25°C~75°C
Physical
Number of Pins 16
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount, Through Hole
