MAX6675ISA+
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Sensor and Detector Interfaces
Description
MAX6675 IC Thermocouple to Digital Converter -20C~85C 4.9mm 1.5mA 2.6V
PDF
/
Buying Options
Total Price: USD $16.24
Unit Price: USD $16.236
≥1 USD $16.236
≥10 USD $12.85152
≥100 USD $12.174624
≥500 USD $10.48388
≥1000 USD $9.807459
Inventory: 992
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Height Seated (Max) 1.75mm
Technical
Current - Supply 1.5mA
Input Type Thermocouple (K)
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 5.5V
Output Type Digital
Output Voltage 2.6V
Qualification Status Not Qualified
Pin Count 8
Base Part Number MAX6675
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Terminal Finish Matte Tin (Sn)
Type Thermocouple to Digital Converter
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2002
Packaging Tube
Operating Temperature -20°C~85°C
Physical
Manufacturer Package Identifier 21-0041 (REV A)
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
