MAX6603ATB+T

Maxim Integrated
RoHS
RoHS RoHS compliant
Package 10-WFDFN Exposed Pad
Category Integrated Circuits (ICs) / Interface - Sensor and Detector Interfaces
Description MAX6603 IC Signal Conditioner -40C~125C 3mm 3.3/5V 5.5mA
PDF
/
Buying Options
Total Price: USD $224
Unit Price: USD $3.2
≥70 USD $3.2
Inventory: 1434
Minimum: 70
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Width 3mm
Length 3mm
Height Seated (Max) 0.8mm

Technical

Current - Supply 5.5mA
Input Type Voltage
Interface Analog
Supply Voltage-Min (Vsup) 3V
Power Supplies 3.3/5V
Supply Voltage-Max (Vsup) 5.5V
Output Type Logic
Qualification Status Not Qualified
JESD-30 Code S-XDSO-N10
Pin Count 10
Base Part Number MAX6603
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position DUAL
Technology BICMOS
HTS Code 8542.39.00.01
Terminal Finish Matte Tin (Sn)
Type Signal Conditioner
ECCN Code EAR99
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 1999
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C

Physical

Surface Mount YES
Package / Case 10-WFDFN Exposed Pad
Mounting Type Surface Mount
