MAX31855SASA+
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Sensor and Detector Interfaces
Description
MAX31855 3.6V 900muA 1.5mm 1.75B
PDF
/
Buying Options
Total Price: USD $9.24
Unit Price: USD $9.24
≥1 USD $9.24
≥10 USD $8.35032
≥100 USD $7.96224
≥500 USD $6.913632
≥1000 USD $6.602904
≥3000 USD $6.020291
Inventory: 83
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Number of Pins 8
Weight 506.605978mg
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Published 2012
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type Thermocouple to Digital Converter
Subcategory Other Analog ICs
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number MAX31855
Pin Count 8
Qualification Status Not Qualified
Output Type Digital
Operating Supply Voltage 3.3V
Interface SPI
Max Supply Voltage 3.6V
Min Supply Voltage 3V
Operating Supply Current 900μA
Max Supply Current 1.5mA
Input Type Thermocouple (Multiple)
Resolution 1.75 B
Dimensions
Height 1.5mm
Length 5mm
Width 4mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
