LT1025ACN8#PBF
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Interface - Sensor and Detector Interfaces
Description
LT1025 IC Thermocouple Conditioner 0C~70C 3.937mm 150muA 5V
PDF
/
Buying Options
Total Price: USD $13.89
Unit Price: USD $13.8864
≥1 USD $13.8864
≥10 USD $10.99384
≥100 USD $10.414976
≥500 USD $8.968432
≥1000 USD $8.389832
≥3000 USD $7.955869
Inventory: 1122
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.62mm
Height Seated (Max) 3.937mm
Technical
Current - Supply 150μA
Input Type Voltage
Supply Voltage-Min (Vsup) 4V
Supply Voltage-Max (Vsup) 36V
Qualification Status Not Qualified
JESD-30 Code R-PDIP-T8
Pin Count 8
Base Part Number LT1025
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
HTS Code 8542.39.00.01
Terminal Finish Matte Tin (Sn)
Type Thermocouple Conditioner
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2002
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Surface Mount NO
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Supply Chain
Factory Lead Time 16 Weeks
