AD9814JRRL
RoHS
/
Package 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - Sensor and Detector Interfaces
Description
AD9814 IC CCD Signal Processor, 14-Bit 0.5LSB 0C~70C 1.75B 2.65mm
PDF
/
Buying Options
Total Price: USD $16.76
Unit Price: USD $16.7599
≥1 USD $16.7599
≥10 USD $13.7522
≥100 USD $13.32185
≥500 USD $12.89245
≥1000 USD $12.46305
Inventory: 1051
Minimum: 1
-
+
Technical Details
Physical
Contact Plating Lead, Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-SOIC (0.295, 7.50mm Width)
Number of Pins 28
Technical
Operating Temperature 0°C~70°C
Packaging Tape & Reel (TR)
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
ECCN Code EAR99
Type CCD Signal Processor, 14-Bit
Max Power Dissipation 450mW
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number AD9814
Pin Count 28
Operating Supply Voltage 5V
Interface Parallel, Serial
Max Supply Voltage 5.25V
Min Supply Voltage 4.75V
Operating Supply Current 90mA
Power Dissipation 355mW
Input Type Logic
Resolution 1.75 B
Sampling Rate 6 Msps
Number of Converters 1
Differential Nonlinearity 0.5 LSB
Dimensions
Height Seated (Max) 2.65mm
Width 7.5mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
