SI3015-BS
RoHS
/
Package 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Modems - ICs and Modules
Description
DUAL Contains Lead GULL WING Surface Mount IC modem 85C 2.4Mbps 3.9mm 3.3/5V
PDF
/
Inventory: 2736
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Number of Pins 16
Weight 189.459863mg
Technical
Packaging Tube
Published 2012
Series ISOmodem?
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature ALSO OPERATES AT 5V SUPPLY
HTS Code 8542.39.00.01
Subcategory Other Telecom ICs
Voltage - Supply 3.3V 5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 225
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number SI3015
Pin Count 16
Qualification Status Not Qualified
Power Supplies 3.3/5V
Temperature Grade INDUSTRIAL
Nominal Supply Current 300μA
Data Rate 2.4 Mbps
Baud Rate 2.4k
Data Format V.90
Dimensions
Height Seated (Max) 1.75mm
Length 9.9mm
Width 3.9mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
