TCA9534DWR
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - I/O Expanders
Description
CA9534 Tape & Reel (TR) ACTIVE (Last Updated: 4days ago) Active io expander 1.8V 10.3mm 400kHz 0.04mA
PDF
/
Buying Options
Total Price: USD $1.21
Unit Price: USD $1.2144
≥1 USD $1.2144
≥10 USD $1.08592
≥100 USD $1.030304
≥500 USD $0.846296
≥1000 USD $0.79112
≥3000 USD $0.699125
Inventory: 558
Minimum: 1
-
+
Technical Details
Physical
Surface Mount YES
Number of Pins 16
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Feature POR
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Technology CMOS
Voltage - Supply 1.65V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Supply Voltage 1.8V
Terminal Pitch 1.27mm
Base Part Number CA9534
Output Type Push-Pull
Interface I2C
Number of I/O 8
Number of Ports 1
Number of Bits 8
Clock Frequency 400kHz
Supply Current-Max 0.04mA
Interrupt Output Yes
Dimensions
Height 2.65mm
Length 10.3mm
Width 7.5mm
Thickness 2.35mm
Compliance
RoHS Status ROHS3 Compliant
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
