PCF8575CDBQR
RoHS
RoHS compliant
RoHS compliantPackage 24-SSOP (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - I/O Expanders
Description
PCF8575 Tape & Reel (TR) ACTIVE (Last Updated: 1week ago) Active io expander 5.5V 8.65mm 400kHz 10mA 25mA
PDF
/
Buying Options
Total Price: USD $2.39
Unit Price: USD $2.38735
≥1 USD $2.38735
≥10 USD $1.9589
≥100 USD $1.8981
≥500 USD $1.83635
≥1000 USD $1.77555
Inventory: 1743
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1.5mm
Width 3.9mm
Length 8.65mm
Height 1.75mm
Technical
Current - Output Source/Sink 10mA 25mA
Interrupt Output Yes
Supply Current-Max 0.2mA
Clock Frequency 400kHz
Number of Bits 16
Number of Ports 2
Number of I/O 16
Interface I2C, SMBus
Power Supplies 5V
Operating Supply Voltage 5.5V
Output Type Open Drain
Qualification Status Not Qualified
Number of Outputs 16
Pin Count 24
Base Part Number PCF8575
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.64mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology CMOS
HTS Code 8542.39.00.01
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
Feature POR
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Weight 129.500622mg
Number of Pins 24
Surface Mount YES
Package / Case 24-SSOP (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
