PCF8574PWRG4
RoHS
/
Package TSSOP
Category Integrated Circuits (ICs) / Interface - I/O Expanders
Description
GULL WING DUAL INDUSTRIAL CMOS io expander 85C 0.1mA 100kHz 6.5mm
PDF
/
Buying Options
Total Price: USD $1.34
Unit Price: USD $1.34235
≥1 USD $1.34235
≥10 USD $1.102
≥100 USD $1.0678
≥500 USD $1.03265
≥1000 USD $0.99845
Inventory: 62304
Minimum: 1
-
+
Technical Details
Physical
Package / Case TSSOP
Surface Mount YES
Number of Pins 20
Weight 76.997305mg
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e4
Moisture Sensitivity Level (MSL) 1
Number of Terminations 20
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Subcategory Parallel IO Ports
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.65mm
Frequency 100kHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 20
Qualification Status Not Qualified
Operating Supply Voltage 6V
Supply Voltage-Max (Vsup) 6V
Power Supplies 3/5V
Temperature Grade INDUSTRIAL
Number of I/O 8
Number of Ports 1
uPs/uCs/Peripheral ICs Type PARALLEL IO PORT, GENERAL PURPOSE
Number of Bits 8
Supply Current-Max 0.1mA
Frequency (Max) 100kHz
Dimensions
Height Seated (Max) 1.2mm
Length 6.5mm
Width 4.4mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
