PCA9554PWR
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Interface - I/O Expanders
Description
CA9554 Tape & Reel (TR) NRND (Last Updated: 3days ago) Not For New Designs io expander 5.5V 5mm 400kHz 10mA 25mA
PDF
/
Buying Options
Total Price: USD $2.26
Unit Price: USD $2.2616
≥1 USD $2.2616
≥10 USD $2.03456
≥100 USD $1.919808
≥500 USD $1.635656
≥1000 USD $1.535846
≥3000 USD $1.343866
Inventory: 1571
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status NRND (Last Updated: 3 days ago)
Physical
Mounting Type Surface Mount
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Surface Mount YES
Number of Pins 16
Weight 61.887009mg
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Feature POR
Pbfree Code yes
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Technology CMOS
Voltage - Supply 2.3V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3V
Base Part Number CA9554
Pin Count 16
Output Type Push-Pull
Operating Supply Voltage 5.5V
Power Supplies 2.5/5V
Interface I2C, SMBus
Number of I/O 8
Number of Ports 1
Number of Bits 8
Clock Frequency 400kHz
Supply Current-Max 0.175mA
Interrupt Output Yes
Current - Output Source/Sink 10mA 25mA
Dimensions
Height 1.2mm
Length 5mm
Width 4.4mm
Thickness 1mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
