PCA9554DBR
RoHS
RoHS compliant
RoHS compliantPackage 16-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Interface - I/O Expanders
Description
CA9554 Tape & Reel (TR) ACTIVE (Last Updated: 3days ago) Active io expander 5.5V 6.2mm 400kHz 10mA 25mA
PDF
/
Buying Options
Total Price: USD $2.17
Unit Price: USD $2.1736
≥1 USD $2.1736
≥10 USD $1.95008
≥100 USD $1.839904
≥500 USD $1.567544
≥1000 USD $1.471853
≥3000 USD $1.287862
Inventory: 659
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mounting Type Surface Mount
Package / Case 16-SSOP (0.209, 5.30mm Width)
Surface Mount YES
Number of Pins 16
Weight 128.593437mg
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Feature POR
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Technology CMOS
Voltage - Supply 2.3V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number CA9554
Pin Count 16
Qualification Status Not Qualified
Output Type Push-Pull
Operating Supply Voltage 5.5V
Power Supplies 2.5/5V
Interface I2C, SMBus
Number of I/O 8
Number of Ports 1
Number of Bits 8
Clock Frequency 400kHz
Supply Current-Max 0.175mA
Interrupt Output Yes
Current - Output Source/Sink 10mA 25mA
Dimensions
Height 2mm
Length 6.2mm
Width 5.3mm
Thickness 1.95mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
