CAT9555HT6I-GT2
RoHS
/
Package 24-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / Interface - I/O Expanders
Description
CAT9555 Tape & Reel (TR) Obsolete I2C SMBus io expander 5.5V 4mm 400kHz 10mA 24mA
PDF
/
Inventory: 7138
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 24-WFQFN Exposed Pad
Surface Mount YES
Number of Pins 24
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2008
JESD-609 Code e4
Feature POR
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
HTS Code 8542.39.00.01
Technology CMOS
Voltage - Supply 2.3V~5.5V
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number CAT9555
Pin Count 24
Output Type Push-Pull
Operating Supply Voltage 5.5V
Interface I2C, SMBus
Number of I/O 16
Number of Ports 2
Nominal Supply Current 160mA
Clock Frequency 400kHz
Interrupt Output Yes
Current - Output Source/Sink 10mA 24mA
Dimensions
Height Seated (Max) 0.8mm
Length 4mm
Width 4mm
Compliance
RoHS Status RoHS Compliant
