MCP25020-E/SL
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - I/O Expanders
Description
GULL WING DUAL CMOS Lead Free I/O Expander -40C~125C 25mA 25MHz 1Mbps
PDF
/
Buying Options
Total Price: USD $3.87
Unit Price: USD $3.872
≥1 USD $3.872
≥10 USD $3.2472
≥100 USD $3.124
Inventory: 207
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154, 3.90mm Width)
Number of Pins 14
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Published 2005
JESD-609 Code e3
Feature EEPROM, POR, PWM
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Parallel IO Port
Technology CMOS
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number MCP25020
Pin Count 14
Output Type Push-Pull
Power Supplies 5V
Interface CAN V2.0b
Number of I/O 8
Nominal Supply Current 20mA
Max Supply Current 20mA
uPs/uCs/Peripheral ICs Type MICROPROCESSOR CIRCUIT
Number of Bits 8
Clock Frequency 25MHz
Data Rate 1 Mbps
Number of Transceivers 1
Interrupt Output No
Current - Output Source/Sink 25mA
Dimensions
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
