MCP23S08T-E/SO
RoHS
RoHS compliant
RoHS compliantPackage 18-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - I/O Expanders
Description
MCP23S08 Tape & Reel (TR) Active SPI io expander 5.5V 2.65mm 10MHz 25mA
PDF
/
Buying Options
Total Price: USD $1.36
Unit Price: USD $1.3552
≥1 USD $1.3552
≥10 USD $1.1264
≥100 USD $1.089
Inventory: 23013
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mounting Type Surface Mount
Package / Case 18-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Number of Pins 18
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2006
JESD-609 Code e3
Feature POR
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 18
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Technology CMOS
Voltage - Supply 1.8V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number MCP23S08
Pin Count 18
Qualification Status Not Qualified
Output Type Push-Pull
Operating Supply Voltage 5.5V
Power Supplies 5V
Number of Channels 1
Interface SPI
Number of I/O 8
Number of Ports 1
Nominal Supply Current 1mA
Power Dissipation 700mW
Number of Bits 8
Clock Frequency 10MHz
Interrupt Output Yes
Current - Output Source/Sink 25mA
Dimensions
Height Seated (Max) 2.65mm
Width 7.5mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
