TDA7332D
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Filters - Active
Description
Tube TDA7332 Band Pass e4 interface filter 5V 8.65mm 57kHz -40C
PDF
/
Inventory: 8938
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 8.65mm
Height Seated (Max) 1.75mm
Technical
Poles and Zeros 8 AND 0
Number of Filters 2
Response BANDPASS
Frequency - Cutoff or Center 57kHz
Filter Order 8th
Filter Type Band Pass
Nominal Supply Current 14mA
Supply Voltage-Min (Vsup) 4.5V
Temperature Grade INDUSTRIAL
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.5V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
Pin Count 14
Base Part Number TDA7332
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Active
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e4
Packaging Tube
Physical
Number of Pins 14
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
