MAX7414EPA+
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Interface - Filters - Active
Description
Tube MAX7414 Butterworth Low Pass Switched Capacitor e3 interface filter 3V 9.375mm 15kHz 85C
PDF
/
Buying Options
Total Price: USD $7.78
Unit Price: USD $7.776503
≥1 USD $7.776503
≥10 USD $7.336321
≥100 USD $6.921064
≥500 USD $6.529303
≥1000 USD $6.159721
Inventory: 1469
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm)
Surface Mount NO
Number of Pins 8
Technical
Packaging Tube
Published 1998
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Technology CMOS
Voltage - Supply 2.7V~3.6V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 2.54mm
Base Part Number MAX7414
Pin Count 8
Operating Supply Voltage 3V
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 3V
Temperature Grade INDUSTRIAL
Supply Voltage-Min (Vsup) 2.7V
Number of Circuits 1
Nominal Supply Current 1.2mA
Filter Type Butterworth, Low Pass Switched Capacitor
Filter Order 5th
Frequency - Cutoff or Center 15kHz
Response LOWPASS
Poles and Zeros 5 AND 0
Dimensions
Height Seated (Max) 4.572mm
Length 9.375mm
Width 7.62mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
