MAX297EPA+
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Interface - Filters - Active
Description
Tube MAX297 Elliptic Low Pass Switched Capacitor e3 interface filter -5V 9.375mm 25kHz 85C
PDF
/
Buying Options
Total Price: USD $18.18
Unit Price: USD $18.1808
≥1 USD $18.1808
≥10 USD $16.77016
≥100 USD $16.016176
≥500 USD $14.320328
≥1000 USD $13.660838
≥3000 USD $13.001366
Inventory: 72
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 7.62mm
Length 9.375mm
Height Seated (Max) 4.572mm
Technical
Response LOWPASS
Frequency - Cutoff or Center 25kHz
Filter Order 8th
Neg Supply Voltage-Nom (Vsup) -5V
Filter Type Elliptic, Low Pass Switched Capacitor
Supply Current-Max (Isup) 22mA
Nominal Supply Current 15mA
Number of Circuits 1
Temperature Grade INDUSTRIAL
Operating Supply Voltage 5V
Pin Count 8
Base Part Number MAX297
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 4.75V~11V ±2.375V~5.5V
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 1996
Packaging Tube
Physical
Weight 930.006106mg
Number of Pins 8
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Factory Lead Time 6 Weeks
