MAX296CWE+
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - Filters - Active
Description
Tube MAX296 Bessel Low Pass Switched Capacitor e3 interface filter -5V 2.65mm 50kHz 70C
PDF
/
Buying Options
Total Price: USD $23.87
Unit Price: USD $23.865896
≥1 USD $23.865896
≥184 USD $9.523777
≥506 USD $9.204742
≥1012 USD $9.047194
Inventory: 1114
Minimum: 1
-
+
Technical Details
Technical
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Voltage - Supply 4.75V~11V ±2.375V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number MAX296
Pin Count 16
Operating Supply Voltage 5V
Temperature Grade COMMERCIAL
Number of Circuits 1
Nominal Supply Current 15mA
Supply Current-Max (Isup) 22mA
Filter Type Bessel, Low Pass Switched Capacitor
Neg Supply Voltage-Nom (Vsup) -5V
Filter Order 8th
Frequency - Cutoff or Center 50kHz
Response LOWPASS
Poles and Zeros 8 AND 0
Pbfree Code yes
JESD-609 Code e3
Published 2010
Packaging Tube
Dimensions
Height Seated (Max) 2.65mm
Width 7.5mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Number of Pins 16
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
