MAX291MJA
RoHS
/
Package CDIP
Category Integrated Circuits (ICs) / Interface - Filters - Active
Description
Bulk e0 Tin/Lead (Sn/Pb) DUAL interface filter -2.375V 2.54mm 25kHz 125C
PDF
/
Inventory: 2475
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Min Operating Temperature -55°C
Terminal Position DUAL
Terminal Form THROUGH-HOLE
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) 20
Pin Count 8
Supply Voltage-Max (Vsup) 5.5V
Power Supplies +-5V
Temperature Grade MILITARY
Supply Voltage-Min (Vsup) 2.375V
Number of Circuits 1
Supply Current-Max (Isup) 22mA
Neg Supply Voltage-Nom (Vsup) -5V
Neg Supply Voltage-Max (Vsup) -5.5V
Neg Supply Voltage-Min (Vsup) -2.375V
Response LOWPASS
Transfer Characteristics BUTTERWORTH
Active Filter Type SWITCHED CAPACITOR FILTER
Center or Cutoff Freq Rng-Max 25 kHz
Order 8TH
Max Operating Temperature 125°C
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1
Part Status Active
Pbfree Code no
JESD-609 Code e0
Published 2010
Packaging Bulk
Dimensions
Width 7.62mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Physical
Number of Pins 8
Surface Mount NO
Package / Case CDIP
