MAX281ACWE
RoHS
/
Package 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - Filters - Active
Description
Non-RoHS Compliant Not Qualified Obsolete GULL WING Filter IC 70C 20kHz 2.65mm -2.375V
PDF
/
Inventory: 1542
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 7.5mm
Height Seated (Max) 2.65mm
Technical
Poles and Zeros 5 AND 0
Number of Filters 1
Response LOWPASS
Neg Supply Voltage-Min (Vsup) -2.375V
Frequency - Cutoff or Center 20kHz
Filter Order 5th
Neg Supply Voltage-Max (Vsup) -8V
Neg Supply Voltage-Nom (Vsup) -5V
Filter Type Bessel, Low Pass Switched Capacitor
Supply Voltage-Min (Vsup) 2.375V
Temperature Grade COMMERCIAL
Power Supplies +-5V
Supply Voltage-Max (Vsup) 8V
Operating Temperature (Max) 70°C
Qualification Status Not Qualified
Pin Count 16
Base Part Number MAX281
Time@Peak Reflow Temperature-Max (s) 20
Reach Compliance Code not_compliant
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~16V ±2.375V~8V
Subcategory Active Filters
Additional Feature ZERO DC ERROR
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Published 1996
Packaging Tube
Physical
Surface Mount YES
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
