MAX271CWG
RoHS
/
Package 24-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - Filters - Active
Description
Non-RoHS Compliant Not Qualified Obsolete GULL WING Filter IC 6.5mA 70C 25kHz 15.4mm
PDF
/
Inventory: 6748
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 24-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Technical
Packaging Tube
Published 2012
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn85Pb15)
Subcategory Active Filters
Technology CMOS
Voltage - Supply 4.74V~16V ±2.37V~8V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Number of Functions 2
Supply Voltage 5V
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 20
Base Part Number MAX271
Pin Count 24
Qualification Status Not Qualified
Operating Temperature (Max) 70°C
Supply Voltage-Max (Vsup) 8V
Power Supplies +-5V
Temperature Grade COMMERCIAL
Supply Current-Max (Isup) 6.5mA
Filter Type Continuous Low Pass
Neg Supply Voltage-Nom (Vsup) -5V
Neg Supply Voltage-Max (Vsup) -8V
Filter Order 2nd
Frequency - Cutoff or Center 25kHz
Response LOWPASS
Number of Filters 2
Transfer Characteristics DIGITALLY OR PIN PROGRAMMABLE
Dimensions
Length 15.4mm
Width 7.5mm
Compliance
RoHS Status Non-RoHS Compliant
