MAX264BEPI+
RoHS
RoHS compliant
RoHS compliantPackage 28-DIP (0.600, 15.24mm)
Category Integrated Circuits (ICs) / Interface - Filters - Active
Description
Tube MAX264 Universal Switched Capacitor e3 interface filter -6.3V 36.83mm 140kHz -40C
PDF
/
Buying Options
Total Price: USD $33.46
Unit Price: USD $33.45805
≥1 USD $33.45805
≥10 USD $27.4531
≥100 USD $26.59525
≥500 USD $25.7374
≥1000 USD $24.87955
Inventory: 1352
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Through Hole
Package / Case 28-DIP (0.600, 15.24mm)
Surface Mount NO
Technical
Packaging Tube
Published 2012
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Technology CMOS
Voltage - Supply 4.74V~12.6V ±2.37V~6.3V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number MAX264
Pin Count 28
Qualification Status Not Qualified
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Supply Voltage-Max (Vsup) 6.3V
Temperature Grade INDUSTRIAL
Filter Type Universal Switched Capacitor
Neg Supply Voltage-Nom (Vsup) -5V
Neg Supply Voltage-Max (Vsup) -6.3V
Filter Order 2nd
Frequency - Cutoff or Center 140kHz
Number of Filters 2
Transfer Characteristics PIN PROGRAMMABLE
Dimensions
Height Seated (Max) 5.08mm
Length 36.83mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
