MAX262ACWG+
RoHS
RoHS compliant
RoHS compliantPackage 24-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - Filters - Active
Description
ROHS3Compliant Lead Free Obsolete GULL WING Filter IC 16mA 70C 140kHz 15.4mm
PDF
/
Buying Options
Total Price: USD $260.83
Unit Price: USD $260.832782
≥1 USD $260.832782
≥10 USD $246.068657
≥100 USD $232.140249
≥500 USD $219.000229
≥1000 USD $206.603998
Inventory: 1229
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 7.5mm
Length 15.4mm
Technical
Transfer Characteristics DIGITALLY PROGRAMMABLE
Number of Filters 2
Frequency - Cutoff or Center 140kHz
Filter Order 2nd
Neg Supply Voltage-Max (Vsup) -6.3V
Neg Supply Voltage-Nom (Vsup) -5V
Filter Type Universal Switched Capacitor
Nominal Supply Current 16mA
Temperature Grade COMMERCIAL
Supply Voltage-Max (Vsup) 6.3V
Pin Count 24
Base Part Number MAX262
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply ±5V
Technology CMOS
Additional Feature IT CAN ALSO BE OPERATED FROM A SINGLE 5V SUPPLY
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Terminal Finish Matte Tin (Sn)
Type Active
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2003
Packaging Tube
Physical
Number of Pins 24
Package / Case 24-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
