5962-9159502MPA
RoHS
RoHS compliant
RoHS compliantPackage /
Category Integrated Circuits (ICs) / Interface - Filters - Active
Description
5962-9159502 e0 Tin/Lead (Sn/Pb) DUAL interface filter -2.5V 2.54mm 125C 10mA
PDF
/
Inventory: 1577
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Lead, Tin
Mount Through Hole
Technical
Published 2003
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 125°C
Min Operating Temperature -55°C
HTS Code 8542.39.00.01
Subcategory Active Filters
Technology CMOS
Terminal Position DUAL
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 2.54mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 20
Base Part Number 5962-9159502
Pin Count 8
JESD-30 Code R-GDIP-T8
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 8V
Power Supplies +-5V
Temperature Grade MILITARY
Supply Voltage-Min (Vsup) 2.5V
Supply Current-Max (Isup) 10mA
Neg Supply Voltage-Nom (Vsup) -5V
Screening Level MIL-STD-883
Neg Supply Voltage-Max (Vsup) -8V
Neg Supply Voltage-Min (Vsup) -2.5V
Response LOWPASS
Transfer Characteristics BUTTERWORTH
Poles and Zeros 5 AND 0
Active Filter Type SWITCHED CAPACITOR FILTER
Order 5TH
