LTC1560-1CS8#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Filters - Active
Description
Tape & Reel (TR) LTC1560 Continuous Low Pass e3 interface filter -4.5V 4.9mm 1MHz 70C
PDF
/
Buying Options
Total Price: USD $7.57
Unit Price: USD $7.568869
≥1 USD $7.568869
≥200 USD $2.92908
≥500 USD $2.826674
≥1000 USD $2.775471
Inventory: 1507
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Technical
Poles and Zeros 5 AND 0
Transfer Characteristics ELLIPTIC
Number of Filters 1
Response LOWPASS
Neg Supply Voltage-Min (Vsup) -4.5V
Frequency - Cutoff or Center 1MHz
Filter Order 5th
Neg Supply Voltage-Max (Vsup) -5.5V
Neg Supply Voltage-Nom (Vsup) -5V
Filter Type Continuous Low Pass
Supply Voltage-Min (Vsup) 4.5V
Temperature Grade COMMERCIAL
Supply Voltage-Max (Vsup) 5.5V
Operating Temperature (Max) 70°C
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G8
Pin Count 8
Base Part Number LTC1560
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 250
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply ±4.5V~5.5V
Technology CMOS
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2003
Packaging Tape & Reel (TR)
Physical
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
