LTC1164-6CSW#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - Filters - Active
Description
Tape & Reel (TR) LTC1164 Elliptic or Bessel Low Pass e3 interface filter -2.375V 3.809mm 30kHz -40C
PDF
/
Buying Options
Total Price: USD $11.26
Unit Price: USD $11.25943
≥1 USD $11.25943
≥10 USD $10.807793
≥30 USD $10.023992
≥100 USD $9.341284
Inventory: 1264
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.62mm
Height Seated (Max) 3.809mm
Technical
Poles and Zeros 8 AND 0
Transfer Characteristics ELLIPTIC/BESSEL
Number of Filters 1
Response LOWPASS
Neg Supply Voltage-Min (Vsup) -2.375V
Frequency - Cutoff or Center 30kHz
Filter Order 8th
Neg Supply Voltage-Max (Vsup) -8V
Neg Supply Voltage-Nom (Vsup) -5V
Filter Type Elliptic or Bessel Low Pass
Supply Voltage-Min (Vsup) 2.375V
Temperature Grade INDUSTRIAL
Power Supplies +-7.5V
Supply Voltage-Max (Vsup) 8V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
Pin Count 16
Base Part Number LTC1164
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~16V ±2.375V~8V
Technology CMOS
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2007
Packaging Tape & Reel (TR)
Physical
Surface Mount YES
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
