LTC1064-1CN#PBF
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Interface - Filters - Active
Description
Tube LTC1064 Cauer Low Pass Switched Capacitor e3 interface filter -2.37V 3.937mm 20kHz -40C
PDF
/
Buying Options
Total Price: USD $28.34
Unit Price: USD $28.336
≥1 USD $28.336
≥10 USD $26.136
≥100 USD $24.961024
≥500 USD $22.31812
≥1000 USD $21.290298
Inventory: 69
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.62mm
Height Seated (Max) 3.937mm
Technical
Poles and Zeros 8 AND 0
Transfer Characteristics ELLIPTIC/BESSEL
Number of Filters 1
Response LOWPASS
Neg Supply Voltage-Min (Vsup) -2.37V
Frequency - Cutoff or Center 20kHz
Filter Order 8th
Neg Supply Voltage-Max (Vsup) -8V
Neg Supply Voltage-Nom (Vsup) -7.5V
Filter Type Cauer, Low Pass Switched Capacitor
Supply Current-Max (Isup) 28mA
Supply Voltage-Min (Vsup) 2.37V
Temperature Grade INDUSTRIAL
Power Supplies +-7.5V
Supply Voltage-Max (Vsup) 8V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
Pin Count 14
Base Part Number LTC1064
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Supply Voltage 7.5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Voltage - Supply ±2.37V~8V
Technology CMOS
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2002
Packaging Tube
Physical
Surface Mount NO
Package / Case 14-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Supply Chain
Factory Lead Time 8 Weeks
