LTC1062CN8#PBF
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Interface - Filters - Active
Description
Tube LTC1062 Butterworth Low Pass Switched Capacitor e3 interface filter -2.5V 3.937mm 20kHz -40C
PDF
/
Buying Options
Total Price: USD $9.06
Unit Price: USD $9.0552
≥1 USD $9.0552
≥10 USD $8.17872
≥100 USD $7.798384
≥500 USD $6.771248
≥1000 USD $6.466909
≥3000 USD $5.896299
Inventory: 280
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm)
Surface Mount NO
Technical
Packaging Tube
Published 1996
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Technology CMOS
Voltage - Supply ±8V 5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number LTC1062
Pin Count 8
JESD-30 Code R-PDIP-T8
Qualification Status Not Qualified
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Supply Voltage-Max (Vsup) 9V
Power Supplies +-5V
Temperature Grade INDUSTRIAL
Supply Voltage-Min (Vsup) 2.5V
Filter Type Butterworth, Low Pass Switched Capacitor
Neg Supply Voltage-Nom (Vsup) -5V
Neg Supply Voltage-Max (Vsup) -9V
Filter Order 5th
Frequency - Cutoff or Center 20kHz
Neg Supply Voltage-Min (Vsup) -2.5V
Response LOWPASS
Number of Filters 1
Poles and Zeros 5 AND 0
Dimensions
Height Seated (Max) 3.937mm
Width 7.62mm
Compliance
RoHS Status ROHS3 Compliant
