LTC1061ACN#PBF
RoHS
RoHS compliant
RoHS compliantPackage 20-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Interface - Filters - Active
Description
ROHS3Compliant Not Qualified Active CMOS Filter IC 15mA -40C 35kHz 26.92mm
PDF
/
Buying Options
Total Price: USD $27.74
Unit Price: USD $27.744203
≥1 USD $27.744203
≥200 USD $10.736896
≥500 USD $10.360094
≥1000 USD $10.173662
Inventory: 1144
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.62mm
Length 26.92mm
Technical
Poles and Zeros 2 AND 0
Transfer Characteristics RESISTOR PROGRAMMABLE
Number of Filters 3
Frequency - Cutoff or Center 35kHz
Filter Order 6th
Neg Supply Voltage-Max (Vsup) -8V
Neg Supply Voltage-Nom (Vsup) -5V
Filter Type Universal Switched Capacitor
Supply Current-Max (Isup) 15mA
Temperature Grade INDUSTRIAL
Power Supplies 5V
Supply Voltage-Max (Vsup) 8V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
JESD-30 Code R-PDIP-T20
Pin Count 20
Base Part Number LTC1061
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 3
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Voltage - Supply 4.74V~16V ±2.37V~8V
Technology CMOS
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2005
Packaging Tube
Physical
Surface Mount NO
Package / Case 20-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Supply Chain
Factory Lead Time 10 Weeks
