UA9638CDG4
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 Rail/Tube Nickel/Palladium/Gold (Ni/Pd/Au) COMMERCIAL interface receiver 5.25V 65mA 72.603129mg 15Mbps
PDF
/
Buying Options
Total Price: USD $6.16
Unit Price: USD $6.161607
≥1 USD $6.161607
≥10 USD $5.812827
≥100 USD $5.483804
≥500 USD $5.173399
≥1000 USD $4.880569
Inventory: 1121
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 3.91mm
Length 4.9mm
Height 1.58mm
Technical
Number of Transmitters 2
Out Swing-Min 2 V
Supply Voltage1-Nom 5V
Driver Number of Bits 2
Interface IC Type LINE DRIVER
Input Characteristics STANDARD
Output Polarity COMPLEMENTARY
Differential Output YES
Output Characteristics TOTEM-POLE
Data Rate 15 Mbps
Nominal Supply Current 65mA
Min Supply Voltage 4.75V
Max Supply Voltage 5.25V
Temperature Grade COMMERCIAL
Power Supplies 5V
Operating Supply Voltage 5V
Pin Count 8
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory Line Driver or Receivers
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 2
JESD-609 Code e4
Packaging Rail/Tube
Physical
Weight 72.603129mg
Number of Pins 8
Surface Mount YES
Package / Case SOIC
